1.Chargingtracker:
Toggle switchto "ON" and insert USB charging cable.
The blue lightflashes, showing that it is under the process of charging.
When the blue lightstops flashing the process of charging isfinished.
2. Start-up thetracker:
Insert SIMcard and toggle switch to "ON".
After 10 seconds,the tracker will be stand-by in normal workcondition.
3.Position:
Use the cellphone to call number of your tracker, then when the call isconnected you cut the call. After a while the tracker will send aweb link to the phone.
Use your phone or yourcomputer to can open this web link. Then it will show the positionof the tracker on the map and it will also show the coordinates ofyour tracker's position to make the position more precise.
Alternatively, you cansend SMS "w" to the tracker.
4.Power saving:
Use your phone to send theSMS "P12" to the number of the tracker. Then the tracker will poweroff and it will be restart after 12 hours. After restarted, thetracker will send a web link by itself, so the owner of trackerwill get the tracker's position.
5.The tracker isonly used for home, children, old people monitoring. And the resultof position is for indication only.
| Specs: | |
| Dimension: | 31.5mm*28mm*11mm |
| Color: | Black |
| Battery: | 150mA standby3~4 days |
| Locationmodel: | GSM celllocation |
| Screen: | No |
| ON OFF: | Support |
| Statuslight: | Oneled |
| Chargepin: | Micro 5 pinusb |
| CPU: | MTK6250D |
| Frequency: | 850/900/1800/1900MHz |
| Microphone: | Yes |
| Functions: | ||
| Operation | Description | |
| Query mode1: | Dialmode | Dial to deviceand end the dialing within |
| Query mode2: | SMSmodel | Send the "w" todevice, the device replies with location |
| Listener: | Dialmode | Dial to device,wait 6 seconds to establish the line |
| Sleepmode: | SMS commandmode | Send the "p12"to device, then the device will enter the sleep mode, after 12hours will auto start up and report the device'slocation |
