Receiver | Type L,C/A code | ||
51-channel acquisition | |||
14-channel tracking n | |||
| Maximum Update Rate | 10Hz | ||
| Accuracy | Position | 10m(2m in WAAS supporting area) | |
| Velocity | 0.1m/sec | ||
| Time To First Fix | Hot-Start | 5 seconds average | |
| Warm-Start | 20 seconds average | ||
| Cold-Start | 2 minutes average | ||
| Protocol | NMEA-0183 v3.01 | ||
| Assistance | Message-based via NMEA serial port | ||
| Supply Voltage | USB DC5V and 3.7V 390MA lithium battery | ||
| Current Consumption | Acquisition | ~70mA | |
| Tracking | ~30mA | ||
| Battery Capacity | 390mA | Around 4 hours | |
| Operation Temperature | -20°C~ +75°C | ||
