| SPECIFICATIONS | |
| Brand name: | RADALL |
| Model: | RD-6650AT |
| Interface type: | USB, supports HID SPP protocol |
| Optical resolution: | 4x10^6 |
| Scan speed: | 280 Hz |
| Max. paper size: | A4 |
| Scanning distance: | 10-800 mm |
| Scan method: | Manual/Automatic (auto-scanning) |
| Scanning angle: | Bow angle 60° (bow), Elevation 65° (yaw) |
| Prompt: | Buzzer, Indicator light |
| Operating temperature: | -20 to 45 °C |
| Voltage: | 5 Volt |
| Working current: | Operation: 85 mA Idle: 36 mA |
| Industrial Grade | IP67, 7 meters drop test |
| Surrounding brightness: | Daylight, max. 80000 Lux |
| Safety: | ROHS class 2 laser product, FCC class B, CE Full quakeproof, waterproof, dustproof, antiknock-design and EMI Shielding |
| Decode error rate: | Less than 1 in 8 million |
| Scanner material: | ABS + PC, flame resistant |
| Scan element type: | Laser |
| Light source: | 650nm laser (safe visible light) |
| Color depth: | 32 Bit |
| Operating channel: | 433 MHz |
| Scanner color: | Black and Orange |
| Decode capability: | All 1D barcodes: Code 39, Full ASC II , Code bar, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, Code 93, Code 128, Code 32, Standard code 39, EAN 128, MSI, EAN 8&13, UPCA & E, Plessey, Databar14, TELEPE, GSI Databar |
| Voltage: | 5 Volt |
| Cable length: | 170 cm |
