Dimension: 31mm x 23mm (including mount)
Weight: 25g (kv1800)(not including connectors)
Diameter of shaft:3mm
Lamination thickness: .2mm
Spec.
Battery: 3 Cell 3S/11.1V
Weight: 25g (kv1800)(not including connectors)
Diameter of shaft:3mm
Lamination thickness: .2mm
Spec.
Battery: 3 Cell 3S/11.1V
RPM: 1800kv
Max current: 10~12A
No load current: 7.4V/0.6A
Current capacity: 16A/20sec
Internal resistance: 0.145ohm
Dimensions: 12x30mm
Pull: 320~450g
Prop: 6x3~9x4.7
ESC: 20A
Max Current: 14A
Battery Type: 2~3SOnly
Max Current: 14A
Battery Type: 2~3SOnly
| A(mm) | - |
| B(mm) | 16 |
| C(mm) | 30 |
| D(mm) | 5 |
| E(mm) | 21 |
